FibroCeram Materials FibroCeram Materials

Refractory High Temperature Thermal Insulation Ceramic Fiber Paper

Still deciding? Get samples of $ !
Order Sample

Product Description

Basic Specifications

Model NO.
BST-CRP
Material
Ceramic
Maximum Voltage
Nm
Thermal Rating
250 250
Near Port
Shanghai, Ningbo
Type
Insulation Paper
Chemistry
Organic Insulation
Classification
Hybrid Insulation Materials
Certification
ISO9001, IATF16949
Transport Package
Carton Box
Specification
Upon request
Origin
China
HS Code
701959
Production Capacity
1000000
Package Size
16.00cm * 16.00cm * 16.00cm
Package Gross Weight
1.000kg

Product Overview

Ceramic fiber paper is produced by high purity ceramic fiber and applied in the higher temperature heat insulation field. The advanced produce technology make the fiber in uniform distribution, also, the thickness of density are controlled strictly. In the production process, a few of binder is added with scientific selection and strictly controland the binder can be burning out in the application process. Ceramic fiber paper with high density is a kind of fiber paper with high strength which is manufactured according to customer's demand. It is with excellent heat insulation property and easy to construction. Also, the ceramic fiber paper is easy to future process (multilayer composite and cut). Ceramic fiber paper with excellent high temperature resistance and heat insulation performance and good melt infiltration resistance,so it is very suitable for using as off isolation casting gasket in building and glass industry.

Product Characteristics

Low heat storage
Low thermal conductivity
Excellent electrical insulation property
Excellent machining process property
High strength, tear resistance
High flexibility
Low shot content

Typical Applications

Industrial heat insulation, sealing and corrosion protection materials
Insulation and heat insulation in instrument equipments and electric heating element
Heat insulation in automotive and aerospace industry
Expansion gap filler materials
Isolation materials in building, metallurgy and glass industry
Molten sealing gasket
Fireproof materials

Technical Parameters

ItemCeramic Fiber Paper
Density (kg/m3)200
Classification Temp. ºC1260
Working Temp. ºC1000
Organic Content<=10%
Loss of Ignition<=10%
Tensile Strength (MPa)>=0.3
Thickness (mm)1, 2, 3, 4, 5, 6
Length (mm)10000 - 40000
Width (mm)610, 1220

Frequently Asked Questions

1. What is the maximum working temperature for this paper?
The ceramic fiber paper has a classification temperature of 1260ºC and a continuous working temperature of 1000ºC.
2. Does it contain organic binders?
Yes, it contains a small amount of organic binder (≤10%) which provides flexibility and strength, and may burn out during the initial heating process.
3. Can the paper be easily cut into specific shapes?
Absolutely. It features excellent machining process properties, making it easy to cut, wrap, or multilayer for custom industrial gaskets and seals.
4. Is ceramic fiber paper a good electrical insulator?
Yes, it offers excellent electrical insulation properties, making it suitable for use in instrument equipment and electric heating elements.
5. What industries typically use this material?
It is widely used in the automotive, aerospace, building, metallurgy, and glass industries for heat insulation and fireproofing.
6. How is the product packaged for shipping?
The product is securely packed in carton boxes to ensure it remains protected and maintains its flexibility during transport.
