FibroCeram Materials
FibroCeram Materials
| Model NO. | Ceramic Fiber Felt |
|---|---|
| Chemical Composition | Al2O3.SiO2, Al2O3 |
| Shape | Ceramic Fiber Plate |
| Manufacturing Technique | Spray Silk Rug |
| Kind | Ordinary Ceramic Fiber |
| Dimensions | Length: 900-2400mm / Width: 500-1200mm |
| Thickness | 3~125mm |
| HS Code | 6806101000 |
| Production Capacity | 8000t |
| Items | 1050F | 1260F | 1260HPF | 1360F | 1400F | 1430F |
|---|---|---|---|---|---|---|
| Permanent Heating Linear Change(%) | 950ºC≤-4 | 1000ºC≤-4 | 1100ºC≤-4 | 1200ºC≤-4 | 1250ºC≤-4 | 1350ºC≤-4 |
| Thermal Conductivity (Average 500ºC) | ≤0.153 W/(m.k) | |||||
| Density(Kg/M3) | 180~250 | |||||
| Al2O3 (%) | ≥40 | ≥43 | 44-47 | 51-53 | 43-45 | - |
| Al2O3+SiO2 (%) | ≥95 | ≥96 | ≥98 | ≥99 | ≥90 | - |
| ZrO2 (%) | - | - | - | - | 5~7 | 15~17 |
Ceramic Fiber Low Density Board is a specialized refractory material formed by adding a quantitative binder to aluminum silicate refractory ceramic fiber followed by a vacuum forming process. The product features a flat shape, small dimensional deviation, and convenient installation, making it an ideal insulation solution for industrial furnaces.
Specializing in high-performance refractory and insulation materials ranging from 500ºC to 2000ºC. Our comprehensive range includes refractory ceramic fiber, bio-soluble fiber, insulating firebricks, and microporous boards. These materials serve critical roles in steel plants, boilers, cement production, ceramics, and petrochemical industries. We focus on providing energy-saving solutions to build sustainable thermal treatment systems globally.
