Basic Specifications
Model NO.:Luyangwool
Chemical Comp.:SiO2, Al2O3.SiO2, Al2O3
Shape:Textile
Kind:Ordinary Ceramic Fiber
Product:Aluminum Silicate Textiles
Material:Ceramic Fiber
Specification:100~300mm
HS Code:68061010
Product Description
LUYANGWOOL® 1260 1400 1430 Ceramic Fiber Textile Tape Rope Cloth / RCF Textile
Luyangwool® ceramic fiber textile is manufactured from high-quality ceramic fiber and viscose fiber, reinforced with either glass filament or stainless steel wire. This versatile product range includes yarn, rope, tape, and cloth, specifically designed for extreme temperature environments such as metallurgical ovens, petrochemical heaters, and ceramic kilns.
Core Features
◈ Excellent thermal shock resistance
◈ Superior thermal stability at high temperatures
◈ Low thermal conductivity for energy efficiency
◈ Flexible and easy to install or fabricate
Typical Applications
✔ Gaskets for industrial furnaces and domestic appliances
✔ High-temperature door seals and kiln car seals
✔ Protective welding curtains and expansion joints
✔ Insulation wrapping for pipes and cables
Technical Parameters
| Description |
Cloth |
Tape |
Yarn |
| Reinforcement |
Glass Fiber |
SS Steel |
Glass Fiber |
SS Steel |
Glass Fiber |
SS Steel |
| Temp Limit (ºC) |
650 |
1000 |
650 |
1000 |
650 |
1000 |
| Density (kg/m³) |
500 |
500-550 |
- |
| Description |
Round Braided |
Square Braided |
Twisted Rope |
Woolen |
| Reinforcement |
Glass |
SS |
Glass |
SS |
Glass |
SS |
Glass |
| Density (kg/m³) |
500 |
500 |
500 |
380 |
Frequently Asked Questions (FAQ)
Q1: What materials are used to reinforce Ceramic Fiber Textiles?
A: Textiles are typically reinforced with either glass filament (for temperatures up to 650°C) or stainless steel wire (for temperatures up to 1000°C).
Q2: What is the maximum continuous use temperature?
A: It depends on the reinforcement. Glass fiber reinforced products are limited to 650ºC, while stainless steel reinforced versions can withstand up to 1000ºC.
Q3: What types of textile products are available?
A: The range includes ceramic fiber cloth, tapes, yarns, and various types of ropes (round braided, square braided, twisted, and woolen).
Q4: Are these products resistant to thermal shock?
A: Yes, ceramic fiber textiles exhibit excellent thermal shock resistance and high-temperature stability.
Q5: What is the typical organic content in these textiles?
A: Most Luyangwool® textiles have an organic content of ≤15%, which may smoke slightly during the initial heating process.
Q6: What are the common density specifications?
A: Typical densities range from 380 kg/m³ for woolen ropes to 500-550 kg/m³ for braided ropes, cloth, and tapes.
